- 1/2″ FPT Inlet – 3/8″ MPT Outlet
- Reversibele Crankcase for Easy Right or Left Hand Mounting
- Increased Fin Depth Increases Surface Area to Maximize Heat Dissipation
- Stainless Steel Unitized Check Valves
- Heat-Resestant Solid Ceramic Plungers Operating on Lubricated Packings
- Direct Drive Mounting Flange
- Reinforced Crankcase for Increased Load Capacity
- Enlarged Crankcase Increases Oil Capacity for Better Lubrication and Lower Operating Temperatures
- One-Piece Industrial-Grade Oversized Bronze Connecting Rods
| TORQUE SETTINGS Nm (Ft. Lb) | ZW Pump |
|---|---|
| Manifold Screw | 10 (7,4) |
| Cap Valve (Aluminum Manifold) | 40 (9,5) |
| Cap Valve (Brass Manifold) | <230 Bar 50 (36,9) |
| >230 Bar 60 (44,3) | |
| Bearings Flange Screw Opposite Shaft Side | 4 (3,0) |
| Crankcase Cover Screw | 9 (6,6) |
| Bearing Flange Screw Shaft Side | 9 (6,6) |
| Piston Nut | 6 (4,4) |
