CAT Pump 2SFX35GES

Technical Specifications Fits Electric Motor, 3/4″, 56C Face Max Flow: 3.5 gpm Max Pressure: 2000 RPM: 3450 Crankcase Capacity: 11.15 oz Max Temp: 160 degrees Fahrenheit Inlet Ports: 3/8″ NPT(F) Outlet Ports: 3/8″ NPT(M) Shaft Diameter: 3/4″

CAT PUMP 2SX35GES Data Sheet & Breakdown Removing Pump Winterizing Torque Chart

Model 2SFX35GES
Max Flow 3.5 gpm
Min Pressure 100 psi
Max Pressure 2000 psi
Inlet Port Size 0.37
Discharge Port Size 0.37
RPM 3450
Drive Type(s) Direct

Material Brass (BB)

Attention: Cat Pumps do not come shipped with oil – please see link below : 6107
